Inganda - Icyiciro LCD Yerekana: Imfashanyigisho ifatika yinganda 6 zingenzi

Inganda - Urwego nu bucuruzi LCD: Icyo icyuho gitwara

Inganda - icyiciro nicyiciro cya injeniyeri, ntabwo ari ikirango cyo kwamamaza. Imbonerahamwe ikurikira irerekana muri make itandukaniro rishobora gupimwa hagati yimiterere yubatswe kubidukikije bigenzurwa n’ibigenewe nyabyo - byoherejwe n’inganda ku isi.

Monitori yubucuruzi ikora kuri dogere 60 itesha agaciro itara ryayo mumezi. Ikibaho 300-nit kibura izuba ryinshi. Imigaragarire yo gukoraho inanirwa na gants ni ikibazo cyumutekano hasi yumusaruro. Ikinyuranyo cyibiciro byibyuma hagati yubucuruzi ninganda hafi ya byose ni bito ugereranije nigiciro cyo hasi cyumurima watsinzwe muri sisitemu yumusaruro cyangwa igikoresho cyagenwe. Gusobanukirwaaho ubucuruzi - amanota yerekana amanota ahinduka ikibazo gifatikani intambwe yambere yo kwerekana ubundi buryo bukwiye.

Inganda esheshatu zishingiye ku nganda - Icyiciro LCD Yerekana

1. Gukora no Gukora Inganda

Ikibaho cya HMI, monitor ya SCADA, hamwe na terefone ya PLC ikora ubudahwema mubidukikije bihuza ubushyuhe bwo hejuru, uduce duto two mu kirere, ibicu bikonje, hamwe no kunyeganyega bikomeje. Ikosa rikunze kugaragara muri uru rwego ni ugusuzugura ubushyuhe bw’ubushyuhe: akanama kagenwe uko ibiro byifashe - mubisanzwe dogere 0 kugeza kuri dogere 50 - bizananirwa imburagihe ku igorofa y’umusaruro isanzwe igera kuri dogere 55-65 hafi y’ubushyuhe -. Abakora bambaye uturindantoki twa PPE bakeneye interineti ikoraho yishura neza, kandi itara ryibidukikije rirashobora gutandukana cyane hagati ya zone. Kuri rusangekuboneka LCD yerekana ibishushanyo mbonera byinganda, urutonde rwibintu bikemura ibibazo bisanzwe HMI no kugenzura porogaramu.

• Umucyo:300-500 nits byibuze; hejuru hafi yumuriro wumwuzure cyangwa idirishya
• Ubushyuhe bukora:Degree 20 kugeza kuri dogere 70
• Kurinda:IP54 cyangwa irenga kubidukikije byafunguye
• Gukoraho:Kurwanya cyangwa gants - ihuza ubushobozi buteganijwe (PCAP)
• Imbaraga zinjiza:Mugari - urwego DC (9–36V) kugirango amashanyarazi ahuze

2. Ibikoresho byubuvuzi nubuzima

Ibikoresho byo kubaga, gukurikirana abarwayi, imiyoboro ya pompe ya infusion, hamwe ningingo - ya - ibikoresho byo gusuzuma byitaweho bishyiraho bimwe mubisabwa cyane byerekana urwego urwo arirwo rwose. Ubuso bugomba kurokoka kwanduza inshuro nyinshi ibitaro - abakozi bo mu rwego rwa - inzoga ya isopropyl, ibinyobwa bya amonium ya quaternary - nta gicu kiboneye cyangwa kwangirika kwubutaka. Kurwanya - ibyingenzi byerekana ni ngombwa munsi - ubukana bwo hejuru bwo kumurika. Muburyo butunganijwe neza, glove - imikorere yo gukoraho ntabwo - yumvikana.

Ingingo imwe yakunze kwirengagizwa mugihe cyo gushushanya: module ya LCD ubwayo ntabwo ifite ibyemezo byubuvuzi. IEC 60601 - 1 kubahiriza bireba ibicuruzwa byarangiye. Iyerekanwa rigomba gutoranywa no kwandikwa hamwe ninzira yo kubahiriza mubitekerezo uhereye kumunsi wambere - utanga isoko adashobora gutanga raporo yikizamini cya EMC cyangwa imenyekanisha ryibintu azatinda cyangwa gutesha agaciro ibyemezo byisubiramo, nikibazo gihenze cyane kuruta guhitamo uwatanze isoko hakiri kare.

• Umucyo:400-700 nits kumiterere itandukanye yo kumurika
• Kuvura hejuru:Inzoga - irwanya, irwanya - ihagaze, irwanya -
• Gukoraho:Glove - ubushobozi bujyanye; Ubusobanuro bwambaye ubusa - ubushobozi bwamaboko yo kwisuzumisha
• Kurinda:Ikibanza cyambere cya IP65 kubikoresho byerekanwe mumazi cyangwa ibikoresho byogusukura
• Inyandiko:Raporo yuzuye ya EMC hamwe na RoHS imenyekanisha ryibikoresho bisabwa kubatanga isoko

3. Ikinyabiziga - Sisitemu Yashizweho na Transport

Fleet telematics paneli, amakuru yumushoferi yerekana, muri sisitemu yo gusuzuma - cab, hamwe na gari ya moshi HMI ihuza ikibazo kimwe cyibanze: gusoma izuba. Kugaragaza 400 - nit biragoye gusoma muri kabine yimodoka munsi yumucyo mwinshi; munsi yizuba ryizuba, irazimira neza. Ikibaho kimwe kigomba kandi kubaho dogere dogere 30 mugitangira gitangira na dogere 80 imbere muri cabine ihagaze mugihe cyizuba - ubushyuhe bwumuriro bukuraho ibyuma byubucuruzi byinshi. Kunyeganyega byongera urugero rwa gatatu rwo kunanirwa: guhuza imiyoboro irekuye, ingingo zagurishijwe zacitse, hamwe no gukorakora byangiritse birasanzwe mubinyabiziga bifite ihindagurika ryimashini. ISO 16750-3 itanga ibipimo ngenderwaho byo gupima ibidukikije. Kubisabwabiramba hanze hanze ikoraho ecran murwego rwo hejuru - imiterere yumuhanda, umucyo umwe nibisabwa kurinda IP birakurikizwa.

• Umucyo:700-1,000 nits byibuze; 1.500 nits kubibaho byerekanwe neza nizuba
• Ubushyuhe bukora:Degree 30 kugeza kuri dogere 80 cyangwa mugari kugirango ikirere gikabije
• Kunyeganyega no guhungabana:Yageragejwe kuri ISO 16750-3 cyangwa ibingana na transport
• Kurinda:IP65 ya cab - ikibaho; IP67 kubikorwa byuzuye byerekanwe
• Ubuso:Kurwanya anti - kurabagirana cyangwa kurwanya -

4. Amavuta, gaze, n'ubucukuzi

Sitasiyo ikurikirana imiyoboro, ibyumba bigenzura ku nyanja, hamwe n’ibikoresho byo gucukura amabuye y’ubutaka bihura n’ubushyuhe kuva kuri dogere 40 kugera kuri dogere 85, umukungugu n’ubushuhe buhoraho, guhindagurika guhoraho, no muri zone zimwe na zimwe, ikirere gishobora guturika. Kubikoresho byashyizwe ahantu hashobora guteza akaga - bisanzwe muri peteroli na gaze yo hejuru, gutunganya imiti, hamwe nubucukuzi bumwe na bumwe - theAmabwiriza ya ATEXi Burayi (IECEx ku rwego mpuzamahanga) ni itegeko risabwa guteranya ibicuruzwa byanyuma. Guhitamo ibice kurwego rwo kwerekana module bigomba gushyigikira iyo nzira yo kubahiriza kuva yatangira gushushanya. Ibikoresho muri uyu murenge bikunze kumara imyaka 10 kugeza kuri 15, kandi amahame amwe akomeye y’ibidukikije akoreshwa mubisabwa kurinda, aho MIL - Ikizamini cya STD-810 cyongeweho ibindi bisabwa.

• Ubushyuhe bukora:Degree 40 kugeza kuri dogere 85 kubikorwa byo hanze no munsi y'ubutaka
• Kurinda:IP67 cyangwa IP68 kubibazo byo kwibiza cyangwa hejuru - gukaraba
• Kubangamira akarere:ATEX / IECEx - guhitamo ibice bihuye na zone zikoreshwa
• Umucyo:500-1,000 nits bitewe n'amatara yo kwishyiriraho
• Ubuzima:Ibikoresho byimyaka 10-15 ubuzima bumara igihe kirekire - umwanya wigihe kiboneka gisabwa gukora

5. Gucuruza Kiosks na Self - Terminal ya serivisi

Kwiyita - serivisi za kiosque, POS itumanaho, imashini zitanga amatike, hamwe no kugenzura amahoteri - muri sisitemu ubu usanzwe ugaragaza inganda - paneli yo mu rwego - ntabwo ari ibidukikije bikabije, ahubwo ni amasaha yo gukora. Kiyosike ikora amasaha 14 kugeza kuri 16 kumunsi, iminsi 365 kumwaka, ikusanya amasaha 5000 kugeza 6.000 kumurimo. Umuguzi - amatara yerekana amanota yagabanijwe ku gice cyuwo musoro wagabanutse ku buryo bugaragara mu mwaka wa mbere woherejwe mu bucuruzi. Kurwanya - kwangiza ibintu byangiza mubikorwa rusange, hamwe na paneli ya IPS igumana ibara ryukuri muburyo bwagutse kuruta uburyo bwa TN ubundi - ingenzi mugihe abakiriya begereye bava muburebure butandukanye. Shakisha ibyacukiosk yerekana interanawenyine - serivisi ya terefone iboneza, cyangwa rebabyuzuye - serivisi ya kiosk yoherejwekubisobanuro birambuye no kuyobora ubuyobozi.

• Umucyo:500-700 nits kubicuruzwa byacururizwaga hamwe nibidukikije
• Gukoraho:Ubushobozi buteganijwe hamwe na anti - kuvura kwangiza
• Kurinda:IP54 yimbere yimbere byibuze kurwanya isuka nibikoresho byoza
• Kureba inguni:Umwanya wa IPS wahisemo ubugari - umukiriya inguni - ahura nibisomwa
• Ubuzima:5+ imyaka yemeje ko haboneka ibice bikomeza

6. Ubuhinzi n’inganda IoT

Abashinzwe kuhira neza, kugenzura amatungo, hamwe na IIoT impande zombi bakorera ahantu hitaruye kandi bafite serivisi nke, bigatuma igihe kirekire - igihe cyo kwizerwa - mu myaka yashize, ntabwo ari amezi - umushoferi wibanze. Ibikoresho byubuhinzi bihura nubushyuhe bukabije, umukungugu, ubushuhe, hamwe no kunyeganyega. IIoT node ikora kumirasire y'izuba cyangwa bateri yongeramo ingufu nke zo guhagarara kurutonde rwibisabwa nyabyo. Serivise y'ibikoresho ibaho imyaka irindwi kugeza ku icumi bivuze ko imihigo iboneka itwara uburemere bwibikorwa.Kwinjiza ubwenge LCD yerekana ibisubizoguhuza imbaraga - igishushanyo mbonera hamwe n’ibipimo by’ibidukikije bigenda bigaragara cyane mu buhinzi bwuzuye n’ibikorwa remezo bya IIoT.

• Ubushyuhe bukora:Degree 20 kugeza kuri dogere 70 kubice bituje; mugari kubihe bikabije
• Kurinda:IP65 byibuze kumurima - ibikoresho byoherejwe
• Gukoraho:Glove - ijyanye nibidukikije bya PPE
• Imbaraga:DC yinjiza neza izuba cyangwa bateri - ikoreshwa na porogaramu
• Ubuzima:Imyaka 7-10 yumurimo ubuzima busaba igihe kirekire - umwanya uhari

Nigute Uhuza LCD Ibisobanuro Kubisabwa

Iyerekana ryiburyo ntabwo aribintu byinshi - ihitamo ryuzuye muri kataloge - niryo ibisobanuro bihuye nibikorwa nyabyo bikora. Gukora binyuze mubyemezo bitanu bikurikiranye birinda amakosa asanzwe kandi ahenze cyane.

Intambwe ya 1: Andika ibidukikije bikora mbere yo gusuzuma ibicuruzwa byose.Ubushyuhe bwubushyuhe, ivumbi nubushuhe bugaragara, urwego rwinyeganyeza, hamwe nuburyo bwo kumurika ibidukikije bitera ibyemezo byihariye. Bimaze kwandikwa, buriwese utanga isoko arashobora gusuzumwa kubisabwa byanditse aho gutekereza kumvugo - kandi iyo nyandiko irinda icyemezo cyubwubatsi ubuzima bwibicuruzwa.

Intambwe ya 2: Shiraho urumuri rushingiye kumuri nyirizina, ntabwo aribyiza -.Ibidukikije bigenzurwa mu nzu mubisanzwe bikenera 300-500. Itara rikomeye ryibidukikije - igorofa yo kugurisha, ahakorerwa uruganda hafi yidirishya, cabine yimodoka - mubisanzwe bisaba 500-800. Imirasire y'izuba isaba byibuze nits 1.000. Kuri porogaramu aho ikibaho cyerekana ibintu bifite akamaro, kugereranya hagatiImiterere ya LCD na LEDikubiyemo ubucuruzi bujyanye - offs.

Intambwe ya 3: Hitamo ikoranabuhanga ryo gukoraho kugirango rihuze abakoresha nukuri.Gukoraho birwanya gukora hamwe na gants, amaboko atose, hamwe na stylus - byizewe mubidukikije cyangwa PPE - ibidukikije bisabwa, ariko bigarukira gusa - gukoraho. Ubushobozi buteganijwe (PCAP) butanga amashusho meza kandi menshi - gukoraho hamwe na glove - uburyo bwo guhuza ibintu, ariko ntabwo byizewe mugihe cyanduye cyane. Kuyoborani ibihe bintu bikwiranye na tekinoroji itandukanye ya touchscreenitanga uburyo bufatika bwo gutangira iki cyemezo.

Intambwe ya 4: Kugenzura igihe kirekire - igihe cyo gutanga isoko mbere yo gukora.Akanama k'abaguzi karahagarikwa kenshi nta nteguza mu mezi 12 kugeza 18 yatangijwe. Ibikoresho byinganda bimara imyaka icumi cyangwa irenga. Baza mu buryo butaziguye: ni ubuhe buryo ubuzima bwiyemeje gukora, ni iherezo - rya - idirishya ryo kumenyesha ubuzima, kandi hari igihe cyanyuma - igihe - cyo kugura? Kubyemezo byamasoko ya B2B kurwego, guteB2B kiosk yerekana amasoko no kuyitunganyaimirimo - harimo ibyangombwa byubuzima busabwa - ishyiraho ibyateganijwe.

Intambwe ya 5: Menya ibyangombwa bisabwa murwego rwo gushushanya, ntabwo urwego rwo kubahiriza.Ibicuruzwa byubuvuzi bikenera IEC 60601 - 1 ibyangombwa biva kubitanga. Ibikoresho byangiza - ibikoresho byakarere bisaba ATEX cyangwa IECEx ibyangombwa. Impamyabumenyi ya CE, FCC, na UL igomba guhuzwa na raporo y'ibizamini bitanga isoko hakiri kare. Kuvumbura icyuho cyinyandiko murwego rwo gusuzuma ibyiciro bisabwa cyane kuruta kubikumira. Iwacukwerekana ibicuruzwa byuzuyeurutonde rwimpamyabumenyi ziboneka kurugero.

Ibibazo Bikunze Kubazwa

Ni ikihe gipimo cya IP ntarengwa cyo kwerekana inganda hanze?

IP65 itanga uburinzi bwuzuye kumukungugu no kumazi ateganijwe kuva icyerekezo icyo aricyo cyose - igorofa ifatika yerekana imbaho ​​zo hanze zerekana imvura cyangwa imashini isanzwe - hasi. IP67 yongerera uburinzi kwibiza byigihe gito, birakwiriye gukoreshwa mumazi hamwe nibidukikije bitunganyirizwa hamwe - gukaraba. Kubikorwa byose byo hanze bidafite uruzitiro rwokwirinda, IP65 igomba gufatwa nkibisobanuro byemewe byemewe, ntabwo ari intego.

Monitori yubucuruzi irashobora gukoreshwa mubidukikije?

Kumucyo - porogaramu zisabwa hamwe nubushyuhe bugenzurwa, amasaha asanzwe yo gukora, hamwe n ivumbi rike cyangwa ubushuhe, ibyuma byubucuruzi birashobora kuba bihagije. Mubidukikije bifite ubushyuhe bukabije, ibikorwa bikomeza 24/7, guhindagurika gukomeye, cyangwa gukaraba bisanzwe, kwerekana ibicuruzwa mubisanzwe birananirana mbere yo kurangiza igicuruzwa kimwe cya sisitemu yinganda. Itandukaniro ryibiciro hagati yubucuruzi nitsinda ryinganda ntirishobora kwerekana neza ingaruka zigihe cyo gutaha cyateganijwe mubikorwa cyangwa byateganijwe.

Ni irihe tandukaniro rifatika riri hagati yo gukoraho no kurwanya ubushobozi bwo gukoresha inganda?

Ibibaho birwanya gusubiza intoki zuzuye, amaboko atose, hamwe na stylus - byizewe mubidukikije byanduye, bitose, cyangwa PPE - ibidukikije bisabwa, ariko bigarukira gusa - gukoraho. Ibikoresho byateganijwe bitanga ishusho nziza kandi isobanutse - ifasha gukoraho hamwe na gants - igaragara neza, ariko irumva cyane kwanduza cyane. Kubisuku - icyumba, ubuvuzi, cyangwa umukiriya - guhangana na porogaramu, ubushobozi ni amahitamo meza; kumurima wo hanze ukoresha, gukora, hamwe na - ibidukikije byanduye, birwanya birashoboka cyane.

Inganda - urwego LCD rumuri rumara igihe kingana iki?

Inganda - urwego rwinyuma rwamatara rusanzwe rushyirwa mumasaha 50.000 cyangwa arenga. Ku masaha umunani yo gukora buri munsi, bivuze hafi imyaka 17 yubuzima bwa serivisi. Akanama - urwego rushobora kuboneka mu nganda zashyizweho n’inganda LCD muri rusange zikorwa mu myaka itanu cyangwa irenga, hamwe n’iherezo ryemewe - ryigihe cyo kumenyesha ubuzima - igihe - kugura igenamigambi - inyungu zifatika kurenza akanama gashinzwe abaguzi, gashobora guhagarikwa nta nteguza mu mwaka umwe cyangwa ibiri yatangijwe.

Niba uri mubyiciro byambere byo kwerekana icyemezo,shikira bitaziguyehamwe nibisobanuro byawe hamwe nibidukikije bikora. Kubitari - bisanzwe bifatika bifatika, ibyacuumurongo - ishusho ya LCD ya ecranikubiyemo ibishushanyo bikwiranye na tekinike - inkombe, ikinyabiziga kibaho, hamwe nibikoresho byashizwemo nibikoresho bisanzwe bitondekanya.
